Z Axis-2F
Dual Frequency Hydrographic Echo Sounder
F1: 200 Khz.
F2: 30, 28, 24, 18, 12, or 10 Khz. (Field Selectable)
Specifications
1.25 inch NPT Pipe Mounting
(optional one inch survey pole adapter is available)
Maximum Depth: 100 meters (330 feet)
Minimum Depth: 0.24 meters. (0.8 feet)
(for BOTH F1 and F2 frequencies)
Ping Rate: 5, 10, or 20 hz. (user selectable)
User Inputs:
Sound Velocity
Offset (Draft)
Units (meters or feet)
Blanking Gate
Depth
Hands-Off Operation
After setup, operation of the Z Axis-2F is fully autonomous with no user intervention
needed.
Seamless Sea Bottom Tracking
Assured by Unabara’s proprietary machine learning algorithm which anticipates changes in bottom
conditions by analyzing the metrics of every returning ping.
Direct Depth Input:
Direct input of depth(s) (Z data) to PC based mapping programs or data collectors (Trimble,
Carlson, Leica, Topcon and others) via RS-232 or USB.
Output Sentences:
· NMEA-XDR
· ODOM DBT
· DESO-20
Baud Rate: 9600 to 115,200 (user selectable).
Simple Setup
Using included Z Axis Windows-based PC Control & Monitoring software APP
Power Input: 12 volts D.C. @ 150ma.
(Optional external battery and charger available)
Narrow Acoustic Beam Widths
• For both F1 (5 degrees) and F2 ( 3.5 degrees).
• Results in small ensonified
footprint of the sea bottom.
• Best horizontal spatial resolution of any survey echo
sounder.
Sediment Thickness
Differences between depths calculated from F1 and F2 frequencies can be used to determine
siltation thickness and locate “liquid mud” in navigation channels. Both of the above are of particular
interest in dredging operations.
Z Axis-2F™ ACCESSORIES & OPTIONS
Adapter to One Inch Survey Pole $36.00 USD
(Adapts 1.25 inch NPT mount on BSU to 5/8 female insert on pole)
Stock # SPA-1
Survey Pole Section (Length = 1 foot)
$39.50 USD
(1 inch O.D., Red-Orange, with 5/8-11 male/female ends)
Stock # SPSE-1OD-RO-1
Tiltable Transom Mount for Survey Pole
$120.00 USD
Stock # TTM-1ODR
(weight = 4 lbs.; 1.8 kg.)
BSU Extension Cable Assembly
$ 197.00 USD
(length = 10 feet; 3.3 meters)
Stock # BSU-EC-10F
(weight = 2
lbs.; 0.9 kg.)
External Rechargeable LiFePO4 Battery
$180.00 USD
Pack (with Charger, AC Input 100 to 240 VAC; 50/60 hz.)
(Fully charged battery
will operate Z Axis-2F™ for ~40 hrs.)
Stock # RBPC-7
(weight = 2 lbs. 2 oz.; 1.8 kg.)
Moulded WK-7 Resin Polymer Carrying Case
$395.00 USD
(Weatherproof, IP-67 rated, suitable for shipping, four double action latches,
gasketed; all stainless steel hardware; internal foam customizable; able to
accommodate all accessory items
listed above; suitable for customer supplied TSA
compliant locks)
Stock # 945Y (Color: Yellow)
(weight = 10.6 lbs.; 4.8 kg.)
(Outside L =
25.1 inches; 638 mm, W = 19.9 inches; 505 mm; H = 8.8 inches, 224
mm)
