Hydro-2F
Multi-Frequency Synthetic Beam Bathymetric & Sea Floor Sonar
Specifications

Frequency Range
200 Khz. (nominal) and 10, 12, 18, 24, 28 or 30 Khz. (User Selectable)

Beamwidth
200 Khz. = 7 deg. (-3 dB); 10/12/18/24/28/30 Khz. = 3.5 deg. (-3 dB)

Transducer Elements
Integrated into Below Surface Unit (BSU)

Electronics
All Integrated into Below Surface Unit (BSU)

Input Power
12 VDC nominal (180 ma. Average; 1 amp.Peak on Transmit)

BSU Size:
6.0 inch Diameter; 5.75 inch Height

BSU Weight:
4 lbs (in air); 1 lb. (in water)

Depth Ranges
Metric = 25m, 50m, 100 m, AUTO
English = 80 ft, 160 ft, 330 ft, AUTO


Maximum Depth
200 Khz. = 100 meters (330 ft.) Low Frequencies = 75 meters (248 ft.)

Calibrated Backscatter Measurement for Bottom Contrasting™

Optional Sediment View Display
